The kit contains:
- 4pcs of Hikvision DS-2CD1043G0-I, 2.8mm fixed lens, IR 30m
- 1pc of 4 channel NVR recorder Hikvision DS-7104NI-Q1
Short technical description of Hikvision DS-2CD1043G0-I, 2.8mm fixed lens, IR 30m
- 1/3" progressive scan CMOS
- Up to 4.0 megapixel
- 2.8mm fixed focal lens
- Up to 30 m IR range
- Dual stream
- Digital WDR (Wide Dynamic Range)
- 3D DNR (Digital Noise Reduction)
- PoE (Power over Ethernet)
- IP67
Short technical description of 4 channel NVR recorder Hikvision DS-7104NI-Q1
Video/Audio Input
- IP video input: 4-ch
- Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
- Incoming bandwidth: 25Mbps
- Outgoing bandwidth: 40Mbps
- Remote connection: 128
Video/Audio Output
- HDMI/VGA output: 1-ch, resolution: 1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
- Audio Output: 1-ch, RCA (Linear, 1kΩ)
Decoding
- Live view / Playback: 1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
- Capability: 4-ch@720P, 2-ch@1080P
Hard Disk
- SATA: 1 SATA interface for 1 HDD
- Capacity: Up to 4TB for each disk
External Interface
- Network Interface: 1 RJ-45 10 / 100 Mbps selfadaptive
Ethernet interface
POE
- Interface: 4 independent 10 /100 Mbps PoE
- Ethernet interfaces
- Max. Power: 35W
- Supported Standard: AF
General
- Power Supply: 48V DC
- Consumption(without hard disk and POE): | ≤ 6 W
- Working Temperature: -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
- Working Humidity: 10 % ~ 90 %
- Chassis: 1U chassis
- Dimensions: 255 × 205 × 45 mm
- Weight(without HDD): ≤ 1 Kg
-
